OpenTDF-RS

A Rust implementation of the OpenTDF (Trusted Data Format) specification, providing data-centric security that travels with the data.

Overview

OpenTDF-RS enables cryptographic binding of access policies directly to data objects, supporting a Zero Trust security model with continuous verification. This library allows secure data sharing across organizations and industries.

Features

  • TDF Archive Creation and Reading
  • Cryptographic Operations (AES-256-GCM encryption)
  • Policy Binding through HMAC-SHA256
  • Streaming Operations for Efficient Data Handling
  • Attribute-Based Access Control (ABAC): Fine-grained access control using attributes
  • Hierarchical Attributes: Support for attributes with inheritance relationships
  • Time-Based Constraints: Policies with validity periods
  • Logical Operators: AND, OR, NOT combinations for complex policies
  • Comprehensive Audit Logging: Detailed records of access attempts and attribute evaluation
  • KAS (Key Access Service) Integration: Full rewrap protocol support for production deployments
  • MCP Server with KAS Support: AI agents can decrypt TDF files using KAS

Attribute-Based Access Control (ABAC)

OpenTDF-RS implements ABAC to provide fine-grained access control that is cryptographically bound to protected data.

ABAC Flow Diagram

Core Components

AttributeIdentifier

Represents a uniquely identifiable attribute with namespace and name:

// Create from string in "namespace:name" format
let attr_id = AttributeIdentifier::from_string("gov.example:clearance")?;

// Or create directly
let attr_id = AttributeIdentifier {
    namespace: "gov.example".to_string(),
    name: "clearance".to_string(),
};

AttributeValue

Supports multiple data types for flexible attribute representation:

// String value
let value = AttributeValue::String("TOP_SECRET".to_string());

// Numeric value
let value = AttributeValue::Number(42.0);

// Boolean value
let value = AttributeValue::Boolean(true);

// Date/time value
let value = AttributeValue::DateTime(chrono::Utc::now());

// Array values
let value = AttributeValue::StringArray(vec!["ENGINEERING".to_string(), "EXECUTIVE".to_string()]);
let value = AttributeValue::NumberArray(vec![1.0, 2.0, 3.0]);

Operators

Rich set of comparison operators for attribute evaluation:

Operator Description Example
Equals Exact match department == "ENGINEERING"
NotEquals Negated match department != "FINANCE"
GreaterThan Numeric comparison age > 21
GreaterThanOrEqual Numeric comparison priority >= 5
LessThan Numeric comparison risk < 3
LessThanOrEqual Numeric comparison level <= 4
Contains String contains name contains "Admin"
In Value in array department in ["HR", "LEGAL"]
AllOf All array values present certifications allof ["ISO", "SOC2"]
AnyOf Any array values present skills anyof ["Rust", "C++"]
NotIn Value not in array restricted_country notin ["US", "EU"]
MinimumOf Hierarchical minimum clearance minimumof "SECRET"
MaximumOf Hierarchical maximum clearance maximumof "TOP_SECRET"
Present Attribute exists employee_id present
NotPresent Attribute doesn't exist terminated notpresent

AttributePolicy

Build complex policy expressions with logical operators:

// Simple condition
let is_executive = AttributePolicy::condition(
    AttributeIdentifier::from_string("gov.example:role")?,
    Operator::Equals,
    Some("EXECUTIVE".into())
);

// Logical AND
let and_policy = AttributePolicy::and(vec![condition1, condition2, condition3]);

// Logical OR
let or_policy = AttributePolicy::or(vec![condition1, condition2, condition3]);

// Logical NOT (using operator overloading)
let not_policy = !condition1;

// Complex nested policy
let complex_policy = AttributePolicy::or(vec![
    AttributePolicy::and(vec![condition1, condition2]),
    AttributePolicy::and(vec![condition3, !condition4]),
]);

Policy Structure

Complete policy with time constraints and dissemination:

// Create policy with attribute conditions and recipients
let policy = Policy {
    uuid: uuid::Uuid::new_v4().to_string(),
    valid_from: Some(chrono::Utc::now()),
    valid_to: Some(chrono::Utc::now() + chrono::Duration::days(30)),
    body: PolicyBody {
        attributes: vec![attribute_policy],
        dissem: vec!["user@example.com".to_string()],
    },
};

ABAC Integration with TDF

The new simplified API makes ABAC policy binding effortless:

use opentdf::{
    Tdf, Policy, AttributePolicy, AttributeIdentifier,
    AttributeValue, Operator
};
use std::collections::HashMap;

// 1. Create policy with attribute conditions
let clearance = AttributePolicy::condition(
    AttributeIdentifier::from_string("gov.example:clearance")?,
    Operator::MinimumOf,
    Some("SECRET".into())
);

let department = AttributePolicy::condition(
    AttributeIdentifier::from_string("gov.example:department")?,
    Operator::In,
    Some(AttributeValue::StringArray(vec![
        "ENGINEERING".to_string(),
        "EXECUTIVE".to_string()
    ]))
);

// Combine with logical AND
let combined_policy = AttributePolicy::and(vec![clearance, department]);

// Create full policy
let policy = Policy::new(
    uuid::Uuid::new_v4().to_string(),
    vec![combined_policy.clone()],
    vec!["user@example.com".to_string()]
);

// 2. Encrypt with ABAC policy - just 4 lines!
Tdf::encrypt(b"Sensitive information")
    .kas_url("https://kas.example.com")
    .policy(policy)
    .to_file("example.tdf")?;

// 3. Later: Evaluate access based on user attributes
let user_attrs = HashMap::from([
    (
        AttributeIdentifier::from_string("gov.example:clearance")?,
        AttributeValue::String("TOP_SECRET".to_string())
    ),
    (
        AttributeIdentifier::from_string("gov.example:department")?,
        AttributeValue::String("ENGINEERING".to_string())
    ),
]);

let access_granted = combined_policy.evaluate(&user_attrs)?;
assert!(access_granted, "User should have access based on attributes");

Common Policy Patterns

Role-Based Restrictions

// Require specific role
let role_policy = AttributePolicy::condition(
    AttributeIdentifier::from_string("org:role")?,
    Operator::Equals,
    Some("ADMIN".into())
);

Multi-Department Access

// Allow access for multiple departments
let dept_policy = AttributePolicy::condition(
    AttributeIdentifier::from_string("org:department")?,
    Operator::In,
    Some(AttributeValue::StringArray(vec![
        "FINANCE".to_string(),
        "LEGAL".to_string(),
        "EXECUTIVE".to_string()
    ]))
);

Clearance Level with Time Restriction

// Require minimum clearance and time-bound access
let clearance_policy = AttributePolicy::condition(
    AttributeIdentifier::from_string("gov:clearance")?,
    Operator::MinimumOf,
    Some("SECRET".into())
);

let policy = Policy {
    uuid: uuid::Uuid::new_v4().to_string(),
    // Valid for next 24 hours only
    valid_from: Some(chrono::Utc::now()),
    valid_to: Some(chrono::Utc::now() + chrono::Duration::hours(24)),
    body: PolicyBody {
        attributes: vec![clearance_policy],
        dissem: vec!["user@example.com".to_string()],
    },
};

Location and Network Restrictions

// Require specific location AND secure network
let location_policy = AttributePolicy::condition(
    AttributeIdentifier::from_string("env:location")?,
    Operator::Equals,
    Some("HEADQUARTERS".into())
);

let network_policy = AttributePolicy::condition(
    AttributeIdentifier::from_string("env:network_type")?,
    Operator::Equals,
    Some("SECURE".into())
);

let security_policy = AttributePolicy::and(vec![location_policy, network_policy]);

Exclude Temporary Contractors

// Employees only (NOT contractors)
let contractor_check = AttributePolicy::condition(
    AttributeIdentifier::from_string("org:employment_type")?,
    Operator::Equals,
    Some("CONTRACTOR".into())
);

let employees_only = !contractor_check;

KAS (Key Access Service) Integration

OpenTDF-RS includes full support for the KAS v2 rewrap protocol, enabling production-ready TDF decryption with centralized key management and access control.

Overview

The KAS protocol allows:

  • Centralized key management: KAS securely stores and manages encryption keys
  • Access control enforcement: KAS validates policies and user attributes before releasing keys
  • Audit logging: All key access attempts are logged for compliance
  • Zero Trust: Keys are never stored with encrypted data

Protocol Flow

1. Client generates ephemeral EC key pair (P-256)
2. Client builds rewrap request with TDF manifest
3. Client signs request with JWT (ES256)
4. Client POSTs to KAS /v2/rewrap endpoint
5. KAS validates policy and user attributes
6. KAS returns wrapped key + session public key
7. Client unwraps key: ECDH → HKDF → AES-GCM decrypt
8. Client decrypts TDF payload

Basic Usage

Enable the KAS feature in your Cargo.toml:

[dependencies]
opentdf = { version = "0.3.0", features = ["kas"] }

Decrypt TDF with KAS

use opentdf::{TdfArchive, kas::KasClient};

#[tokio::main]
async fn main() -> Result<(), Box<dyn std::error::Error>> {
    // Create KAS client
    let kas_client = KasClient::new(
        "http://kas.example.com/kas",
        "your-oauth-token-here"
    )?;

    // Open and decrypt TDF in one call
    let plaintext = TdfArchive::open_and_decrypt(
        "encrypted-file.tdf",
        &kas_client
    ).await?;

    println!("Decrypted: {}", String::from_utf8_lossy(&plaintext));
    Ok(())
}

Manual Decryption

For more control over the decryption process:

use opentdf::{TdfArchive, kas::KasClient};

#[tokio::main]
async fn main() -> Result<(), Box<dyn std::error::Error>> {
    // Create KAS client
    let kas_client = KasClient::new(
        "http://kas.example.com/kas",
        "your-oauth-token-here"
    )?;

    // Open TDF archive
    let mut archive = TdfArchive::open("encrypted-file.tdf")?;
    let entry = archive.by_index()?;

    // Decrypt using KAS
    let plaintext = entry.decrypt_with_kas(&kas_client).await?;

    // Access manifest and policy
    let policy = entry.manifest.get_policy()?;
    println!("Policy: {:?}", policy);

    Ok(())
}

Testing with Real KAS

Integration tests are available that work with a real KAS server:

# Set environment variables
export KAS_URL="http://10.0.0.138:8080/kas"
export KAS_OAUTH_TOKEN="your-token-here"

# Run KAS integration tests
cargo test --features kas --test kas_integration -- --ignored --nocapture

KAS Error Handling

The KAS client provides detailed error information:

use opentdf::kas::{KasClient, KasError};

match kas_client.rewrap_standard_tdf(&manifest).await {
    Ok(key) => println!("Successfully unwrapped key"),
    Err(KasError::AccessDenied(reason)) => {
        eprintln!("Access denied: {}", reason);
    }
    Err(KasError::AuthenticationFailed) => {
        eprintln!("Invalid OAuth token");
    }
    Err(KasError::HttpError(msg)) => {
        eprintln!("HTTP error: {}", msg);
    }
    Err(e) => {
        eprintln!("KAS error: {}", e);
    }
}

Interoperability

⚠️ Compatibility Note: opentdf-rs follows the official OpenTDF specification with camelCase field names in TDF manifests (encryptionInformation, keyAccess, etc.). OpenTDFKit (Swift) currently uses non-standard snake_case field names and is incompatible. See INTEROPERABILITY.md for detailed compatibility matrix and workarounds.

The Rust KAS client is fully interoperable with:

  • platform/sdk (Go): ✅ Fully compatible (spec-compliant)
  • otdfctl (Go): ✅ Fully compatible (golden implementation)
  • OpenTDF Platform: ✅ Production KAS deployments
  • OpenTDFKit (Swift): ❌ Incompatible (uses snake_case - bug in Swift SDK)

TDF files created by spec-compliant SDKs (Go, Rust) can be decrypted across platforms using KAS.

Security Considerations

Cryptographic Algorithms

OpenTDF-RS uses industry-standard cryptographic primitives:

  • Symmetric Encryption: AES-256-GCM (Authenticated Encryption with Associated Data)
  • Key Wrapping (Standard TDF): RSA-2048 with OAEP padding
  • Key Agreement (NanoTDF): ECDH with P-256 curve + HKDF-SHA256
  • Policy Binding: HMAC-SHA256
  • JWT Signing: ES256 (ECDSA with P-256)

⚠️ SHA-1 Deprecation Notice

RSA-OAEP Padding: The current implementation uses SHA-1 for RSA-OAEP padding to maintain compatibility with the OpenTDF Go SDK (platform). SHA-1 has known collision vulnerabilities (see SHAttered attack).

  • Why SHA-1? Required for cross-platform interoperability with existing OpenTDF implementations
  • Risk Level: Low in this context (used for padding, not primary security)
  • Mitigation: RSA-2048 key size and OAEP construction provide defense-in-depth
  • Future: Migration to SHA-256 planned for entire OpenTDF ecosystem

Transport Security

When using KAS in production:

  • Always use HTTPS/TLS for KAS communication (never plain HTTP in production)
  • Validate TLS certificates - consider certificate pinning for high-security deployments
  • Secure OAuth tokens - use short-lived tokens, never hardcode credentials
  • Network isolation - deploy KAS in a protected network segment

Key Management Best Practices

  • Ephemeral keys: Generated fresh for each KAS request, never reused
  • Key rotation: Support for KAS key rotation through multiple key access objects
  • Audit logging: All key access attempts should be logged for compliance
  • Access policies: Enforce attribute-based access control (ABAC) at KAS layer

Data-at-Rest Security

  • TDF archives use authenticated encryption (AES-256-GCM) preventing tampering
  • Policy binding cryptographically ties access policies to encrypted data
  • Key wrapping ensures payload keys are never stored in plaintext
  • Zero Trust: Encryption keys separated from encrypted data

Compliance Considerations

  • FIPS 140-2: AES-256-GCM and RSA-2048 are FIPS-approved algorithms
  • NIST SP 800-38D: AES-GCM implementation follows NIST guidelines
  • Note: SHA-1 usage may impact certain compliance requirements - evaluate for your use case

For security vulnerabilities, please see SECURITY.md (if available) or file an issue.

MCP Server

OpenTDF-RS includes an implementation of the Model Context Protocol (MCP) server, allowing AI assistants and other tools to interact with TDF capabilities via a standardized API.

MCP Server Tools

The MCP server provides the following tools:

Tool Name Description
tdf_create Creates a new TDF archive with encrypted data
tdf_read Reads contents from a TDF archive. Supports optional KAS decryption with kas_url and kas_token parameters
encrypt Encrypts data using TDF encryption methods
decrypt Decrypts TDF-encrypted data
policy_create Creates a new policy for TDF encryption
policy_validate Validates a policy against a TDF archive
attribute_define Defines attribute namespaces with optional hierarchies
user_attributes Sets user attributes for testing access control
access_evaluate Evaluates whether a user with attributes can access protected content with detailed audit records
policy_binding_verify Verifies the cryptographic binding of a policy to a TDF

All access attempts and attribute evaluations are comprehensively logged for compliance and auditing purposes. The audit logging system captures detailed information about each operation, including:

  • The requesting entity identifiers
  • Complete sets of attributes presented
  • Attribute sources and verification status
  • Detailed evaluation results for each attribute in the policy
  • Final access decisions with timestamps
  • Policy version information

Running the MCP Server

To run the MCP server and interact with it via Claude or other MCP-compatible clients:

cargo run -p opentdf-mcp-server

The server listens on stdio for JSON-RPC messages, making it compatible with tools like Claude Code that use the MCP protocol for communication.

Using with Claude Code

Claude Code can connect to the MCP server to perform TDF operations:

claude --mcp="cargo run -p opentdf-mcp-server"

This starts Claude with the MCP server, allowing you to use TDF capabilities directly within the chat interface.

Example commands:

# Create TDF
/mcp opentdf tdf_create {"data": "SGVsbG8gV29ybGQh", "kas_url": "https://kas.example.com", "policy": {"uuid": "sample-uuid", "body": {"attributes": [{"attribute": "gov.example:clearance", "operator": "MinimumOf", "value": "secret"}], "dissem": ["user@example.com"]}}}

# Read TDF (without decryption)
/mcp opentdf tdf_read {"tdf_data": "<base64-encoded-tdf-data>"}

# Read and decrypt TDF using KAS
/mcp opentdf tdf_read {"tdf_data": "<base64-encoded-tdf-data>", "kas_url": "http://10.0.0.138:8080/kas", "kas_token": "your-oauth-token"}

ABAC Testing with MCP

The MCP server supports comprehensive ABAC functionality testing:

# Basic ABAC testing
node tools/test-mcp.js

# Comprehensive attribute access logging test
node tools/audit-logging-test.js

These scripts demonstrate:

  1. Attribute namespace definition with hierarchies
  2. User attribute assignment
  3. Policy creation with attribute conditions
  4. TDF creation with policy binding
  5. Access evaluation based on attributes
  6. Policy binding verification
  7. Comprehensive audit logging and compliance reporting

The audit logging test generates detailed compliance reports in the tools/reports directory. See tools/audit-guide.md for more information on the audit logging system.

Development

MCP Server Development

The MCP server implements the JSON-RPC 2.0 protocol over stdio to provide TDF capabilities to clients. When developing or extending the MCP server:

  1. Tool Definitions: Define tools with both schema and inputSchema fields for compatibility
  2. Protocol Version: Use the latest MCP protocol version (currently "2024-11-05")
  3. Response Format: Ensure all responses follow the JSON-RPC 2.0 specification
  4. Error Handling: Use standard JSON-RPC error codes (-32xxx)
  5. Testing: Use tools/test-mcp.js to verify functionality

If adding new tools, remember to:

  • Add the tool to both the initialize response and listTools response
  • Implement proper parameter validation
  • Follow the JSON-RPC request/response flow
  • Document the tool in this README

Getting Started

Installation

Add to your Cargo.toml:

[dependencies]
opentdf = "0.3.0"

Basic Usage - Simple API ✨

The new simplified API makes TDF encryption incredibly easy:

use opentdf::{Tdf, Policy};

// Create a policy
let policy = Policy::new(
    uuid::Uuid::new_v4().to_string(),
    vec![],
    vec!["user@example.com".to_string()]
);

// Encrypt data - just 4 lines!
Tdf::encrypt(b"Sensitive data")
    .kas_url("https://kas.example.com")
    .policy(policy)
    .to_file("example.tdf")?;

Encrypt a File

use opentdf::{Tdf, Policy};

let policy = Policy::new(
    uuid::Uuid::new_v4().to_string(),
    vec![],
    vec!["user@example.com".to_string()]
);

Tdf::encrypt_file("input.txt", "output.tdf")
    .kas_url("https://kas.example.com")
    .policy(policy)
    .mime_type("text/plain")
    .build()?;

With Attribute-Based Access Control (ABAC)

use opentdf::{
    Tdf, Policy, AttributePolicy, AttributeIdentifier,
    AttributeValue, Operator
};

// Create policy with attribute conditions
let clearance = AttributePolicy::condition(
    AttributeIdentifier::from_string("gov.example:clearance")?,
    Operator::MinimumOf,
    Some("SECRET".into())
);

let policy = Policy::new(
    uuid::Uuid::new_v4().to_string(),
    vec![clearance],
    vec!["user@example.com".to_string()]
);

// Encrypt with ABAC policy
Tdf::encrypt(b"Classified information")
    .kas_url("https://kas.example.com")
    .policy(policy)
    .to_file("classified.tdf")?;

License

This project is licensed under [LICENSE].

About

OpenTDF in Rust community-driven

Topics

rust opentdf

Resources

Readme

License

MIT license
Activity
Custom properties

Stars

5 stars

Watchers

0 watching

Forks

1 fork
Report repository

Releases

No releases published

Packages

No packages published

Contributors 2

  •
  •

Languages
